Time Attendance & Access Control
- Technical Info
- Description
| Display | 4.3" TFT Touch Screen |
| Face capacity | 3,000 (1:N) |
| Fingerprint capacity | 4,000 |
| ID Card capacity | 10,000 (optional) |
| Logs capacity | 100,000 |
| Communication | TCP/IP, USB Host |
| Standard Functions | Automatic Status Switch, Self-Service Query, Work Code, SMS, DST, T9 Input, 9 Digit User ID, Scheduled Bell, Photo ID, ADMS |
| Interfaces for | 3rd Party Electric Lock, Door Sensor, Exit Button, Alarm |
| Wiegand Signal | Output |
| Optional functions | ID/Mifare/HID Cards, Wi-Fi, 3G, 2000 mAH Backup Battery |
| Power supply | 12V 3A |
| Verification Speed | =1 sec |
| Operating Humidity | 20%-80% |
| Dimension | 193.7*164.5*112.5mm (Length*Width*Thickness) |
| Package weight | 1.6 kg |
- 3,000 face and 4,000 fingerprint templates
- Multi-language
- High verification speed
- Advanced and user-friendly UI
- Optional built-in battery backup, providing approximately 4 hours of continuous operation
- New Framework firmware, easy to extend functions and customize client’s requirements
- One face template is registered for one user only
- Able to detect whether the face is an actual face or a photo, enhancing the security level of verification
