Access Control

Time Attendance & Access Control

Fingerprint Capacity	3000
ID Card Capacity	10,000 (Optional)
Record Capacity	100,000
Display	3-inch Screen
Communication	RS232/485, TCP/IP,USB-host
Standard Functions	Workcode, SMS, DST, Scheduled-bell, Self-Service Query, Automatic Status Switch, Webserver, External Printer, 5 digit user ID, Multiple Verify Mode
Optional Functions	ID/Mifare/HID, Photo ID, ADMS, Webserver, External Bell and Printer
Software	ZKTime. Net 3.0
Power Supply	DC 5V 0.8A
Verification Speed	= 1 Sec.
Operating Temp.	0 °C- 45 °C
Operating Humidity	20%-80%
Dimension	190 × 135.8 × 51.5mm (Length × Width × Thickness)
Net Weight	0.70 kg

Intuitive and stunning UI designed with the most popular and internationalized factor.
Interface operation adopts modularized hierarchical design. Simpler, Better and More logical.
Faster matching speed: less than 1 second.
Easy to extend functions and customize customers’ demand.
Support user validity settings.
Support data backup and retrieve.
Support advanced Workcode consisted of letters and numbers.
Support chip encryption for firmware protection.
Support more flexible menu configuration: double line text display.
Support external printer for attendance records output (Optional).
