Time Attendance & Access Control
- Technical Info
- Description
| Fingerprint Capacity | 8000 |
| ID Card Capacity | 10,000 (Optional) |
| Record Capacity | 200,000 |
| Display | 3.5-inch Screen |
| Communication | TCP/IP, RS232/485, USB (host & Client) |
| Standard Functions | Workcode, SMS, DST, Scheduled-bell, Self-Service Query, Automatic Status Switch, T9 input, 9 digit user ID, and photo-ID, ADMS |
| Optional Functions | ID/Mifare/HID, Webserver, and Wi-Fi |
| Software | BioTime |
| Power Supply | DC 12V 1.5A |
| Verification Speed | = 1 sec |
| Operating Temp. | 0°C- 45°C |
| Operating Humidity | 20%-80% |
| Dimension | 192×140×41mm (Length×Width×Thickness) |
| Gross Weight | 1.05 kg |
- Intuitive and stunning UI designed with the most popular and internationalized factor.
- Interface operation adopts modularized hierarchical design. Simple, better and logical.
- Faster matching speed: less than 1 second.
- User validity settings.
- Data backup and retrieve.
- Advanced User ID consisting of letters and numbers.
- Chip encryption for firmware protection.
- More flexible menu configuration: double line text display.
- Easy to extend functions and customize customers demand.
