| NOMINAL IMPEDANCE | 8Ω |
| SENSITIVITY | 86dB (2.83V/ 1m) |
| FREQUENCY RESPONSE | 70 - 20kHz (+/-6dB) With back can/rear enclosure |
| CROSSOVER FREQUENCIES | 2.3kHz |
| DRIVE UNITS | LF: 115mm / HF: 19mm |
| RECOMMENDED AMPLIFIER POWER | 15 - 80W |
| FEATURES | Uni-Q Array, UL2043 & UL1480-5 approved, 8Ohm or 70V: 4w, 8w, 15w, 30w, 100V: 8w, 16w, 30w |
| PRODUCT EXTERNAL DIMENSIONS | Diameter / Depth : 220mm (8.66in.) / 160mm (6.30in.) |
| CUT-OUT DIMENSIONS | Diameter : 196mm (7.71in.) |
| MOUNTING DEPTH FROM SURFACE | With back can : 157mm (6.18in.) |
| UNIT MEASUREMENT | Piece |
