| Camera |
Image Sensor |
1/2.7" CMOS |
| Effective Pixels |
1928(H)×1088(V), 2.1MP |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
PAL: 1.3s~1/30000s
NTSC: 1s~1/30000s |
| Minimum Illumination |
0.03Lux/F1.4, 0Lux IR on |
| S/N Ratio |
More than 65dB |
| IR Distance |
Up to 60m (197feet) |
| IR On/Off Control |
Auto / Manual |
| IR LEDs |
1 |
| Lens |
| Lens Type |
Motorized lens / Fixed iris |
| Mount Type |
Board-in |
| Focal Length |
3.6mm (2.8mm, 6mm, 8mm Optional) |
| Max Aperture |
F2.0 |
| Angle of View |
H: 99°~37° (41°-17.5°) |
| Focus Control |
Auto / Manual |
| Close Focus Distance |
800mm (500mm, 1800mm)
31.50 (19.69, 70.87) |
| Video |
| Resolution |
1080P (1920×1080) |
| Frame Rate |
25/30fps@1080P, 25/30/50/60fps@720P |
| Video Output |
1-channel BNC HDCVI high definition video output & 1-channel BNC CVBS video output CVBS tester out |
| Day/Night |
Auto (ICR) / Manual |
| OSD Menu |
Multi-language |
| BLC Mode |
BLC / HLC / WDR |
| WDR |
120dB |
| Gain Control |
AGC |
| Noise Reduction |
2D |
| White Balance |
Auto / Manual |
| Smart IR |
Auto / Manual |
| Eelectrical |
| Power Supply |
12V DC ±25% |
| Power Consumption |
Max 5W (12V DC, IR on) |
| Environmental |
| Operating Conditions |
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
* Start up should be done at above -30°C (-22°F) |
| Storage Conditions |
-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
| Ingress Protection &Vandal Resistance |
IP67 & IK10 |
| Construction |
| Casing |
Aluminium |
| Dimensions |
Φ110mm×95.5mm (Φ4.33"×3.76") |
| Net Weight |
0.29kg (0.64lb) |
| Gross Weight |
0.43kg (0.95lb) |
