| Camera | Image Sensor | 1/3” 3Megapixel progresive CMOS |
| Effective Pixels | 2304(H) x1536(V) |
| RAM/ROM | 256MB/16MB |
| Scanning System | Progressive |
| Minimum Illumination | 0.78Lux/F2.0(Color), 0Lux/F2.0(IR on) |
| S/N Ratio | More than 50dB |
| IR Distance | Distance up to 10m(33ft) |
| IR On/Off Control | Auto/ Manual |
| IR LEDs | 24 |
| Lens | |
| Lens Type | Fixed |
| Mount Type | Board-in |
| Focal Length | 2.8mm |
| Max. Aperture | F2.0 |
| Angle of View | H:100°/77°, V:55°/42° |
| Focus Control | Fixedx |
| Close Focus Distance | N/A |
| PTZ | |
| Pan/Tilt/Rotation Range | Pan:0° ~360° ;Tilt:-10° ~90° ;Rotation:0° ~360° |
| Video | |
| Compression | H.264/H.264B/H.264H/MJPEG |
| Streaming Capability | 2 Streams |
| Resolution | 3M(2048×1536)/3M(2304×1296)/ 1080P(1920×1080)/1.3M(1280×960)/ 720P(1280×720)/VGA(640 ×480)/ QVGA(320×240) |
| Frame Rate | 3M(1~20fps)/2M(1~25/30fps) VGA/QVGA(1~25/30fps) |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H264:32K ~ 10240Kbps |
| Day/Night | Auto(ICR) / Color / B/W |
| BLC Mode | BLC / HLC / DWDR |
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D DNR |
| Motion Detetion | Off / On (4 Zone, Rectangle) |
| Region of Interest | Off / On (4 Zone) |
| Electronic Image Stabilization (EIS) | N/A |
| Smart IR | Support |
| Defog | 16x |
| Flip | 0°/90°/180°/270° |
| Mirror | Off / On |
| Privacy Masking | Off / On (4 Area, Rectangle) |
| Audio | |
| Compression | G.711A;G.711Mu;AAC |
| Network | |
| Ethernet | HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP; IGMP; SNMP |
| Protocol | HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP;NTP; Bonjour; 802.1x; Multicast; ICMP; IGMP; SNMP |
| Interoperability | ONVIF, PSIA, CGI |
| Streaming Method | Unicast / Multicast |
| Max. User Access | 10 Users/20 Users |
| Edge Storage | NAS Local PC for instant recording Mirco SD card 128GB |
| Web Viewer | IE, Chrome, Firefox, Safari |
| Management Software | Smart PSS, DSS, Easy4ip |
| Smart Phone | IOS, Android |
| Interface | |
| Video Interface | N/A |
| Audio Interface | N/A |
| RS485 | N/A |
| Alarm | N/A |
| Electrical | |
| Power Supply | DC12V, PoE(802.3af)(class0) |
| Power Consumption | <5W |
| Environmental | |
| Operating Conditions | -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH |
| Strorage Conditions | -40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH |
| Ingress Protection | N/A |
| Vandal Resistance | N/A |
| Construction | |
| Casing | Plastic |
| Dimensions | Φ78.5mm×127.8mm(3.09'’ x5.03’’) |
| Net Weight | 0.685Kg (1.51lb) |
| Gross Weight | 0.45Kg (0.99lb) |
