SD-SMART-LWA-G9
SES 9-button LED touch screen
- Wall mount, Touch panel with 9 buttons
- Available in black and white glass colors
- Control your lights, dimmers and RGB color
- Set your RGB LEDs Color for each button
- Lock and unlock the panel by Fixed pattern
Specification
|
|
| Touch Type | Capacitive |
| IR receiver | IR receiver |
| Using Panel Addition 3R | 3 Relay Output 3A/5A |
| Using Panel Addition 3DL-12V | 12V DC 50mA Output |
| Using Panel Addition 2DL-IRE | IR Emitter |
| Number of devices on 1 line | Max. 64 |
| Bus voltage | 12-32 V DC |
| Current consumption | <45 mA / 24 V DC |
| Protection | Reverse Polarity Protection |
| Reaction time | approx. 20ms |
| Touch buttons | 9 touch buttons |
| Backlight | 8 RGB indicators |
| IR receiver | Music, scene, lights control |
| Without packaging | 180 g |
| Width × length × height | 90mm (94mm peak) × 129mm × 13mm |
| Materials | PC anti fire / Glass in front |
| IP rating | IP 50 |
