DS-2CD6924G0-IHS(/NFC)
8 MP 180° PanoVu Network Camera
- Built-in heater, ultra-low temperature start up to -40℃
- 180° splicing image to present all scenes that covered by the camera
- Water and dust resistant (IP67) and vandal proof(IK10)
- Smart human density counting and public behaviors analysis to increase public area safety
Specification
 |
|
| Camera Image Sensor | 1/1.8" Progressive Scan CMOS |
| Max. Resolution | 2.8 mm, Panorama+ePTZ mode: panorama channel: 1920 × 1080; ePTZ channel: 1920 × 1080, Panorama mode: 3840 × 2160, Original mode: 1920 × 1080, 6 mm, Panorama+ePTZ mode: panorama channel: 2400 × 400; ePTZ channel: 1920 × 1080, Panorama mode: 6480 × 1080, Original mode: 1920 × 1080 |
| Shutter Time | 1/25 s to 1/100,000 s |
| Angle Adjustment | Pan: 0° to 355°, tilt: 0° to 90° |
| Day & Night | IR cut filter. Blue glass module to reduce ghost phenomenon. |
| Lens Lens Type | Fixed focal lens, 2.8 mm and 6 mm optional, four lenses |
| Focal Length & FOV | 2.8 mm: horizontal FOV 180°, vertical FOV 90°, 6 mm: horizontal FOV 180°, vertical FOV 25° |
| Lens Mount | M16 |
| Focus | Manual, semi-auto |
| Aperture | F1.4 |
| Video Main-Stream | 2.8 mm, Panorama+ePTZ mode: panorama channel: 50Hz: 25fps (1920 × 1080, 1280 × 720), 60Hz: 30fps (1920 × 1080, 1280 × 720); ePTZ channel: 50Hz: 25fps (1920 × 1080, 1280 × 720), 60Hz: 30fps (1920 × 1080, 1280 × 720), Panorama mode: 50Hz: 25fps (3840 × 2160 , 2560 × 1440 , 1920× 1080), 60Hz: 30fps (3840 × 2160 , 2560 × 1440 , 1920× 1080), Original mode: 50Hz: 25fps (1920× 1080), 60Hz: 30fps (1920× 1080), 6 mm, Panorama+ePTZ mode: panorama channel: 50Hz: 25fps (2400 × 400), 60Hz: 30fps (2400 × 400); ePTZ channel: 50Hz: 25fps (1920 × 1080, 1280 × 720), 60Hz: 30fps (1920 × 1080, 1280 × 720), Panorama mode: 50Hz: 25fps (6480 × 1080, 4800 × 800, 3600 × 600), 60Hz: 30fps (6480 × 1080, 4800 × 800, 3600 × 600), Original mode: 50Hz: 25fps (1920 × 1080), 60Hz: 30fps (1920 × 1080) |
| Sub-Stream | 2.8 mm, Panorama mode: 50Hz: 25fps (1280 × 720, 640 × 360), 60Hz: 30fps (1280 × 720, 640 × 360), 6 mm, Panorama mode: 50Hz: 25fps (2400 × 400, 1920 × 320, 1440 × 240), 60Hz: 30fps (2400 × 400, 1920 × 320, 1440 × 240) |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 65 Mbps |
| H.264 Type | Baseline Profile / Main Profile / High Profile |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Audio Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM) |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/48 kHz |
| Environment Noise Filtering | Yes |
| Network Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| Simultaneous Live View | Up to 20 channels |
| User / Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, control timeout settings, TLS 1.2, TLS1.0, TLS1.1 |
| Network Storage | microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR |
| Client | iVMS-4200 |
| Image Image Settings | Rotate mode (only the original mode supports), saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser |
| Day / Night Switch | Day / Night / Auto / Schedule / Triggered by Alarm In |
| Wide Dynamic Range (WDR) | Digital WDR |
| Image Enhancement | BLC, HLC, 3D DNR, Defog, EIS (only the original mode supports) |
| General Power | 12 VDC, 1.6 A, max. 24 W, three-core terminal block, PoE: 802.3at, 42.5 V to 57 V, 0.5 to 0.4 A |
| Dimension | 189.5 × 207.63 × 206.62 mm (7.46" × 8.17" × 8.13") |
| Storage Conditions | -40 °C to +60 °C (-40 °F to +140 °F), humidity 95% or less (non-condensing) |
| Startup and Operating | -40 °C to +60 °C (-40 °F to +140 °F), humidity 95% or less (non-condensing) |
